10000 LPH Reverse Osmosis Water Treatment Plant

What is a 10000 LPH RO Plant?

A large-scale industrial water purification system designed to produce 10,000 liters per hour (10 tons/hour) of purified water via reverse osmosis technology. Equipped with a 0.0001μm RO membrane, it removes 98% of dissolved salts, heavy metals, bacteria, and organics, meeting strict standards for drinking water, industrial processes, and desalination. The system features one-button automatic operation, modular construction for easy installation, and durable components (dual-phase steel 2507 pumps, SS316L raw water pump) for long-term reliability.

Core Features

✅ High-Volume Production: 10,000 LPH capacity, suitable for medium-to-large industrial facilities (e.g., 240,000 liters/day for 24/7 operation).
✅ Advanced Automation: PLC+relay dual-mode control with online conductivity meter for real-time water quality monitoring.
✅ Energy Efficiency: Ultra-low pressure RO membrane design reduces high-pressure pump energy consumption by 15-20% vs. standard systems.
✅ Membrane Protection: Automatic flushing + dosing system prevents scaling/fouling, extending membrane life to 2-3 years.
✅ Corrosion Resistance: SS316L raw water pump and dual-phase steel 2507 high-pressure pump withstand harsh water conditions (e.g., brackish/seawater).

10000 lph RO plant specification

(Each part is optional, for reference)

What's the cost of 10000 lph RO plant?

Price Range: $15,000–$40,000 (varies by configuration, materials, and supplier).
Key cost factors:

• Pretreatment: Multi-media filters, activated carbon units, and antiscalant dosing systems.
• Membrane Quantity: 8040-type RO membranes (typically 12–16 pieces for 10,000 LPH).
• Material Upgrades: SS304/316L frame vs. carbon steel; UV/ozone post-treatment.
• Warranty: 1-year standard warranty, with optional 3-year extended service.

Application Scenarios

• Chemical & Pharmaceutical: Raw material water, process water, and pure water for drug synthesis.
• Food & Beverage: Bottled water production, beverage processing, and brewery water treatment.
• Power Generation: Boiler feed water to prevent scaling and corrosion in turbines.
• Desalination: Brackish water/seawater desalination for coastal or arid-region municipal supply.
• Electronics: Ultrapure water for semiconductor manufacturing and circuit board cleaning.

FAQ

Q1: What is the footprint of a 10000 LPH RO plant?

A: ~8m × 3m × 2.5m (length × width × height), requiring a flat, concrete foundation with drainage.

Q2: How long does installation take?

A: Modular design allows on-site assembly in 5–7 days (excluding civil work and piping).

Q3: What is the typical recovery rate?

A: 50–60% (varies by raw water quality), with optional concentrated water recycling systems to improve efficiency.

Q4: Does the system require operator training?

A: Minimal training needed-PLC control with touchscreen interface and automatic alerts for faults/ maintenance.
