10 Cartridge Filter Housing
Flow: 0-1.1 m³/H
In/out pipe: 1/2″F and more
Max pressure: 8.6 bar (125PSI)
Max temperature: 0-60°C
Height: 10 inches
Mounting type: Installed directly on the pipe
The 10 Cartridge Filter Housing is a robust commercial-grade solution built to meet heavy filtration demands over the long term. Engineered with high-quality materials, it can withstand the rigors of continuous use in various industrial and commercial settings. This housing is incredibly versatile, as it can accommodate any industry-standard 2.5" x 10" filter cartridge. Whether you need to use pleated, melt-blown, string, gradient density, carbon, or specialty filters, this housing provides a reliable home for them all.
The 10 Cartridge Filter Housing is designed to ensure a secure and tight fit for the cartridges, preventing any bypass of unfiltered water. Its sturdy construction guarantees that it can handle high-pressure environments without leakage or structural failure. This makes it suitable for various applications, from water treatment plants to food and beverage processing facilities.
Specification
|
Product name |
10 inch Cartridge Filter Housing |
|
Size |
10 inches (others also available) |
|
Flow |
0-1.1 m³/H |
|
Housing color |
Blue, clear |
|
Number of O-ring |
2 Double O-ring |
|
In/out pipe |
1/2″F |
|
Maximum withstand pressure |
125 psi (8.8kg/㎡) |
|
Maximum endurance temperature |
140F (60°C) |
|
Burst pressure test |
500psi |
|
Pressure cycle test |
0-150 psi, 100,000 cycles |
10 Cartridge Filter Housing Features
Pressure Relief Safety Mechanism: Equipped with a built-in pressure relief button to safely release excess pressure, ensuring operational security during maintenance or system shutdowns.
High-Strength Material Construction: Combines a polycarbonate housing with a polypropylene cap, offering chemical resistance, durability, and lightweight performance for demanding environments.
Leak-Proof Sealing Technology: Features a top-seated Buna-N O-ring that compresses tightly within the housing's sump, creating a reliable, leak-free seal even under fluctuating pressures.
Reinforced Structural Design: Thick walls and integrated ribbing enhance rigidity and impact resistance, making the housing suitable for industrial, commercial, and municipal applications.
Advanced Buttress Thread System: The precision-engineered thread design ensures superior sealing and secure assembly, minimizing the risks of loosening or leakage over time.
High-Performance Ratings: Rated to withstand temperatures up to 125°F and pressures up to 100 psi, ensuring stability in rigorous operating conditions.
Universal Compatibility: Designed for 10-inch commercial setups, it supports seamless integration with standard cartridges while prioritizing safety with its pressure relief feature.
